Product Overview
This OSRAM constant voltage LED driver is a reliable and efficient power supply for your LED strip lights and modules. It offers a high power output of 250W and a stable 24V DC output voltage, ensuring consistent and flicker-free performance for your lighting setups. While the driver itself isn't dimmable, it's compatible with 24V dimmer controllers, allowing you to adjust the brightness of your connected LEDs with ease.
Key details at a glance:
- Dimensions: 400mm (L) x 40mm (W) x 22mm (H)
- Power: 250W
- Output voltage: 24V DC
- Output current: 0-10420mA
- Dimmable: Use with a 24V dimmer controller to dim your LEDs
For more details, see the full technical specifications on the corresponding tab.
Technical Specifications
| Name | OSRAM Constant Voltage LED Driver 24V 250W 10A for LED Strips-Modules |
| Product Code | 890-15955 LV250W24CG |
| Power | 250W |
| Type | Constant Voltage 24V DC |
| Voltage | 220/240V AC 50/60Hz |
| Output Voltage | 24V DC |
| Output Current | 0-10420mA |
| Power Range | 0-250W |
| Led Type | for LED Modules and LED Strip lights |
| Output | 2 output |
| Protection Class | Class II |
| Dimmability | Non-Dimmable but can be used with 24V dimmer controllers for dimming the LEDs |
| Flickering | Flicker-free |
| IP Class | IP20 |
| Product Dimensions (LxWxH) (DxH) | 400x40x22mm |
| Made Of Materials | Plastic Box |
| Product Colour | White |
| Input Cable Size | 0.75 - 1.5 mm |
| Output Cable Size | 0.75 - 1.5 mm (1.5 mm for if Pout > 150W) |
| Power Factor | pf>0.95 |
| Operating Temperature (C) | -25/+45C |
| Temperature (tc) | 90C |
| Warranty | 3 year |
| Life Span | 50000h |
| Box Dimension (LxWxH) | xxmm |
| Box Content | 1 Piece of driver |
| Certifications | UKCA, CE, ENEC, EAC, SELV |
